1. Building Facade Signage Ratios & Dimensions
On-premise commercial identification signs mounted on building facades or entry arcades are regulated based on building front elevation area:
- Maximum 15% Facade Area Cap: The total cumulative surface area of all wall-mounted signage on any building elevation must not exceed 15% of the total ground floor facade area (or maximum 60 square meters, whichever is less).
- Vertical Elevation Limits: Wall-mounted tenant signs must not extend above the roof parapet level or overhang public footpaths by more than 0.60 meters (600mm).
- Clear Clearance Height: Signage mounted over pedestrian walkways or retail arcades must maintain a minimum vertical head clearance of at least 2.75 meters from the ground surface.
2. Digital LED Billboards & Luminance Caps
Electronic digital billboards and illuminated display screens are subject to strict photometrical controls to prevent glare hazards:
- Maximum Daytime Luminance (5,000 Nits): Outdoor digital LED billboards must not exceed a maximum brightness of 5,000 nits ($\text{cd/m}^2$) during daylight hours.
- Automatic Nighttime Dimming (500 Nits): Between dusk and dawn, digital screens must automatically dim to a maximum luminance of 500 nits via ambient light sensors.
- Prohibition of Flashing / Motion Video near Junctions: Full-motion video displays and rapid flashing animations are strictly prohibited on billboards situated within 100 meters of any signalized road intersection or expressway exit ramp.
The table below outlines DSIRDA outdoor commercial signage specifications:
| Signage Category | Max. Allowed Surface Area | Height Limit / Clearance | Max. LED Brightness (Day / Night) | Structural Wind Rating | Intersection Setback |
|---|---|---|---|---|---|
| **Retail Fascia Sign** | 15% of Ground Facade | Min. 2.75m Headroom | 2,000 / 300 Nits | IS 875 Compliant | N/A (On-Premise) |
| **Ground Pylon Sign** | 12.0 sq. meters | Max. 6.0m Overall Height | 3,000 / 400 Nits | 47 m/s Basic Wind Speed | 15.0 Meters |
| **Corporate Tower Wall** | 60.0 sq. meters | Below Roof Parapet | 3,500 / 500 Nits | Structural Engineer Cert. | 20.0 Meters |
| **Digital LED Billboard** | 50.0 sq. meters | Max. 12.0m Top Height | 5,000 / 500 Nits | 47 m/s (Zone V Seismic) | 100.0 Meters |
3. Structural Certification & Prohibited Signage
- IS 875 Wind Load Certification: All freestanding ground pylon signs and rooftop billboards must be designed by a DSIRDA-registered structural engineer to withstand basic wind speeds of 47 m/s (169 km/h) under IS 875 structural codes.
- Prohibited Sign Locations: Roof-mounted billboards on residential buildings, inflatable advertising blimps, signs attached to public utility poles or trees, and signs obstructing fire escape routes are strictly illegal inside Dholera SIR.
Frequently Asked Questions (FAQ)
#### What is the maximum allowable area for commercial facade signs in Dholera?
Under DSIRDA GDCR Section 9.5, wall-mounted commercial signs cannot exceed 15% of the ground floor facade area or a maximum cap of 60 square meters.
#### What is the nighttime brightness limit for digital LED billboards in Dholera?
Digital screens must automatically dim to a maximum luminance of 500 nits ($\text{cd/m}^2$) during nighttime hours to prevent driver glare.
#### Are billboards allowed near traffic signals in Dholera SIR?
Full-motion digital video billboards are prohibited within 100 meters of any signalized intersection or expressway exit ramp to maintain road safety.
